Product Specifications
AC INPUT
AC Input Voltage Range 85V-270 VAC
Nominal AC Input Voltage 230 VAC​
Nominal Input AC Frequency 50 Hz​
Maximum AC Input Current 8.5 A​
Power Factor > 0.98 @ 230 VAC​
Input Current THD < 5%
​Nominal AC Input Current 5.8 A @ 230 VAC
7.4 A @ 180 VAC
​
DC OUTPUT
Maximum DC Output Voltage 48 / 60 / 72 V
Maximum DC Output Power 1200 W
Battery Type Lead Acid/Li-ion/Ni- Cd/LFP/NMC
Reverse Polarity Yes
Output Overcurrent/Short Circuit Protection Electronic current limit / Fuse
MECHANICAL
Dimensions 228 x 190 x 82.5 mm Weight ~ 2.6kg
AC Input/Output Connector Automotive grade M3 threaded connector
Cooling Active cooling with fan
REGULATORY
Efficiency 92% @ full load Communication CAN 2.0
Protections Input Over voltage protection, Input Under voltage protection, Output over- voltage protection, output under voltage protection, Input overcurrent protection, over temperature protection
ENVIORNMENTAL
Enclosure IP67 (NEMA 4)
Operating Temperature Upto 50°C
